JEOL UK News
Press releases, announcements, awards, and news
We are deeply saddened by the passing of Her Majesty Queen Elizabeth II. As we join the rest of the country in this period of national mourning and allow our staff to pay their respects, the JEOL (UK) Ltd. office will be closed on the day of Her Majesty Queen Elizabeth II’s State Funeral: Monday 19 September
We invite you to join our lunch symposiums during EUROMAR 2022. No need to register, places will be offered on a first-come, first-serve basis.
We look forward to seeing you in Utrecht!
Date: Monday, 11th July, 2022
Time: 12:45 - 13:45
Room: Megaron, Educatorium, Utrecht University
‘XtaLAB Synergy-ED: Micro-crystal electron diffraction made easy’
Dr. Robert Bücker, RIGAKU
‘Electron NMR crystallography: structure solution to microcrystals’
Dr. Yusuke Nishiyama
* 100 pieces of Japanese fried chicken Bento Box will be served
Date: Tuesday, 12th July, 2022
Time: 12:45 - 13:45
Room: Megaron, Educatorium, Utrecht University
‘Smaller, easier and faster New NMR system from JEOL ECZ Luminous’
Dr. Jumpei Hamatsu
‘JEOL's JASON: a new tool for NMR’
Dr. Manuel Perez
* 100 pieces of Japanese fried shrimp Bento Box will be served
We are proud to be sponsoring EUROMAR 2022 again this year, in the beautiful city of Utrecht, The Netherlands!
EUROMAR covers all aspects of Magnetic Resonance, including Nuclear Magnetic Resonance (NMR), Electron Spin Resonance (ESR), and Magnetic Resonance Imaging (MRI). It combines keynote and invited lectures, lectures selected from abstracts, and poster sessions. It is the European conference to discuss all aspects of Magnetic Resonance and network with vendors and colleagues.
Join us on July 10-14, 2022.
Follow us on social media (@JEOLEUROPE, @JEOLJASON) for updates about JEOL's activities and events at EUROMAR 2022.
We looking forward to welcoming you all to the JEOL booth. See you in Utrecht!
The latest version of our next-generation NMR analytical software 'JASON' is out now!
Easy to acquire data for all specimen types...
With the JSM-IT510, the newly added Simple SEM function allows users to "leave the manual repetitive operation to it", required for SEM observation, making SEM observation more efficient and easier.
Click here for full product information.
The ECZ Luminous (JNM-ECZL series) is an FT NMR spectrometer equipped with state-of-the-art digital and high frequency technology. The highly integrated Smart Transceiver System, a high-speed, high-precision digital high-frequency control circuit, enables further miniaturization and high reliability of the spectrometer. It is capable of high-field and solid-state NMR measurements while maintaining the size of a conventional low-field solution NMR system.
The new Multi Frequency Drive System enables multi-resonance measurements in a standard configuration, providing a wider range of solutions.
Click here for more info.
The 2021 edition of the JEOL NEWS magazine is now available to download.
- Progress in Photonic Crystal Lasers and Their Application to LiDAR
- And Yet It Moves: Molecular Rotors and Motors Studied by Solid-State NMR Spectroscopy
- Dioxins Analysis with New GC-MS/MS System and Software "TQ-DioK"
- Characterization of Localized Physical Properties Using High Resolution EELS
- In-Resin CLEM of Epon-Embedded Cells Using Fluorescent Proteins
- Degradation Analysis for Polymer Materials by Spin-Trapping
- High-Speed Electron Beam Modulation System Using Electrostatic Deflection and Laser Delivery System to the Specimen in Transmission Electron Microscopy
- The New Detection System of High-End FE-SEM JSM-IT800 Super Hybrid Lens ＜SHL＞
- Preparation of TEM Specimens Having Specific Crystal Orientations Using FIB-SEM and EBSD ～ Applications to Allende meteorite ～
- Chemical Bonding State Analysis of Boron and Phosphorus Compounds by Soft X-ray Emission Spectroscopy and Electronic Structure Calculations
- Chemical State Analysis of Fe in the Matrix of the Allende Meteorite Using an FEG EPMA and SXES
- MultiAnalyzer – Unknown Compounds Analysis System New Gas Chromatograph Time-of-Flight Mass Spectrometer JMS-T2000GC "AccuTOF™ GC-Alpha"
- Introduction of JEOL Products
Congratulations to our esteemed colleague Dr. Hideyuki Takahashi at JEOL Ltd. for winning the 2021 'Presidential Science Award' from the Microanalysis Society (MAS) for his long-term contribution to the field of microbeam analysis. He has been engaged in R&D and application development of electron probe microanalyzer and soft X-ray emission spectrometer since he joined JEOL.
We would like to thank Takahashi-san for all his hard work and dedication.
Data from a JEOL 300kV TEM, JEM-ARM300F, and a new laser system by IDES, Inc. will be presented by the research team of AIST and Osaka University at M&M 2021.
The research group of Dr. Ryousuke Senga, Electron Microscopy Group, Nanomaterials Research Institute, Advanced Industrial Science and Technology (AIST) and Professor Kazutomo Suenaga, Department of Nanocharacterization for Nanostructures and Functions, Nanoscience and Nanotechnology Center, The Institute of Scientific and Industrial Research (ISIR: SANKEN), Osaka University, succeeded in recording atomic-resolution in-situ movies of growing carbon nanotubes and onion-shaped carbon nano structures in a transmission electron microscope (TEM). The structures were formed by laser irradiation of samples made of carbon films and iron nanoparticles.
This experiment was conducted using a JEOL 300kV Transmission Electron Microscope with a cold field emission gun, JEM-ARM300F, and a new system designed by JEOL subsidiary Integrated Dynamic Electron Solutions, Inc. for precisely focusing lasers onto TEM samples, Luminary Micro. This combination of high-performance imaging instrumentation and reduced sample motion due to precision-controlled rapid localized illumination enables extraordinary spatial resolution for in-situ experiments.
The details of this research will be presented by Dr. Senga during the Microscopy and Microanalysis (M&M) 2021 Conference, held in the U. S. from 1st - 5th August 2021.
See the movies and full press release here.
We would like to welcome all EUROMAR 2021 delegates to join the JEOL events throughout the conference. You can still register for EUROMAR 2021 here.
On Tuesday 6th July, JEOL will be hosting a User Meeting with special guest speakers Professor Ulla Gro Nielsen from the University of Southern Denmark (SDU) and Professor Martin Dračínský from the Czech Academy of Sciences.
Click here for the full schedule of JEOL Events.
See you there!
JEOL Live Demo Shows at mmc2021 - BOOK NOW!
Click here for more information.
Taking place for the first time virtually! mmc2021 will encompass an international scientific virtual conference (6 - 8 July) of six parallel streams, covering an enormous range of microscopy, cytometry and imaging topics. (The conference sessions will be recorded and available after their live scheduled time for those who registered for mmc2021. The recordings will be made available to view for a few weeks after mmc2021).
A huge FREE to ATTEND virtual exhibition (6 - 8 July) with companies both large and small showcasing their latest equipment and available to answer your questions
Virtual meetings & workshops covering the latest emerging topics (5 - 9 July)
Join the JEOL Commercial Workshops:
Tuesday 6 July at 12:45 – 13:15 BST
Presented by Andy Yarwood
Wednesday 7 July at 10:00 – 10:30 BST
‘Interface upgrades provide high-level control over JEOL TEM operation’
Presented by Bart Marzec
Wednesday 7 July at 12:15 – 12:45 BST
‘With open ARMs – JEOL Corrected Microscopy solutions for widening your capabilities’
Presented by Calum Dickinson
And don't forget to stop by our virtual exhibiton stand for information about our live demo shows.
See you there!
JASON is next-generation analytical software with special emphasis on the automatic processing, analysis, and reporting of NMR data.
Click here to find out more.
Missed our latest TEM and SEM webinar series? You can now catch up and watch them on-demand!
- 'Getting that Image - The TEM Column'
- 'More Than Just an Image - Dark Field and Diffraction'
- 'What's Gone Wrong - Common Issues on the TEM'
- 'Out in the Cold: CryoTEM'
- 'Discovering the Sparkle - Advanced Materials Techniques'
- 'Introduction to Scanning Electron Microscopy'
- 'Detectors and Optimisation of Images...looking at small things'
- 'Spectroscopy (EDS) in the SEM - how to find and identify impurities'
- 'Advanced imaging and spectroscopy and looking at tiny things'
- 'Addressing common sample issues'
We have a new position that needs to be filled in our Oxford office working with our NMR software development team. Click here for the full job description.
To apply: please email your CV to email@example.com. Application deadline: 1st June 2021.
We have an exciting new opportunity to join our high-end TEM service team at JEOL (UK) Ltd, providing service support for JEOL advanced TEM users in Israel.
Click here for the full job description.
The Alpha takes you to a new world of mass spectrometry.
JEOL Ltd. (President & COO Izumi Oi) announces the release of JMS-T2000GC "AccuTOF™ GC-Alpha", the latest model of the successful AccuTOF™ GC series gas chromatograph – time-of-flight mass spectrometers, to be released in February 2021. This product is a GC-MS that represents a significant improvement in performance and functionality using two newly developed Key Technologies. The basic hardware performance has been greatly improved and a new generation of automated data analysis software is included in the standard configuration.
JEOL Ltd. announces the release of a new cold field emission cryo-electron microscope (cryo-EM), the CRYO ARM™ 300 II (JEM-3300), to be released in January 2021. This new cryo-EM has been developed based on the concept of "Quick and easy to operate and get high-contrast and high-resolution images".
CRYO ARM™ 300 II is a cryo-electron microscope that specializes in the observation of electron beam-sensitive specimens, such as protein, for single particle analysis, tomography, and MicroED. This system offers improved stability, throughput and ease of use compared to the previous generation of cryo-EMs. Moreover, this is an all-in-one system that can handle everything from screening to data acquisition, allowing for more flexibility in operation at the customer sites to meet the needs of the facility. These improvements allow users to obtain high-quality images by simple operations even for those who have never used an electron microscope before.
Past JEOL webinar recordings are now available for you to watch on-demand.
JEOL and Advanced Chemistry Development, Inc. (ACD/Labs) announced they have concluded a distribution agreement for ACD/NMR software.
NMR Predictor Suite software has a structure predictive function that can predict an NMR spectrum from chemical structure information, among ACD/NMR software. It is a tool that can perform structural analysis easily. For a user who is considering the purchase of an NMR for the first time, it will be a valuable source of structural analysis information.
We are pleased to share that the paper by Prof. Ido Kaminer and team at Technion – Israel Institute of Technology has been published in Nature.
Prof. Ido Kaminer uses our Transmission Electron Microscope "JEM-2100Plus" and the equipment made by INTEGRATED DYNAMIC ELECTRON SOLUTIONS, INC. (California, USA), which became our wholly-owned subsidiary in January 2020.
We would like to inform you that JEOL UK is still operating as normal under the exceptional circumstances posed by the current COVID-19 crisis. Our Sales and Service departments are open and we have plans in place to continue this as events develop.
As usual, if you need assistance with your JEOL instrument, customers can email us on firstname.lastname@example.org or contact your usual engineer directly.
Many common problems can be resolved over the telephone; however, we are looking at supporting live video calls with JEOL Engineers to offer an increased level of service. There is no change to our policy should you require a visit from a Service Engineer, however, we will be asking you to kindly complete a short questionnaire prior to any on-site visit for the safety of our staff.
We appreciate that some customers may be working in multi-user environments or deciding to shut down instruments for possibly an unknown period. If you need advice on these matters, please contact us if you haven’t already done so.
Understandably, over the next few weeks, we will be prioritising breakdown visits to certain customers (hospitals and those undertaking biological research). Thank you in advance for your patience and understanding if this results in any delay in our service to you.
General Manager Customer Support
After the latest announcement from the UK government regarding measures against the COVID-19 virus, we are aware that many institutions and facilities may be closed for an unknown period.
Unlike other equipment, NMR systems, specifically Super Conducting Magnets, cannot be simply switched off. Cryogen levels (liquid helium and liquid nitrogen) within the magnet need to be maintained to keep the magnet functioning.
JEOL always recommends a weekly nitrogen fill helium fill well before the minimum refill level is reached. We do however appreciate that this may be or could become difficult in the near future.
Regarding nitrogen, most magnets can in fact go two weeks between fills. Minimum safe helium levels vary between magnets. We can advise on this if required.
Should the nitrogen not be maintained, eventually the helium consumption would rise significantly. Once the helium level drops below a critical point, by either lack of nitrogen or a delayed helium fill, the magnet will cease to be super-conducting and dump its energy (a quench). Most of what cryogens remain can be quickly released as gas when this happens.
Although magnets are designed to cope with an unexpected quench, there is always the risk of mechanical damage should this happen. But in most cases, the magnet could be reinstalled. This would however be at considerable cost and with lengthy downtime in the interim.
We would therefore ask that every effort is made and priority is given to maintain the cryogen levels of the magnet.
If at some stage it becomes clear that this cannot be done, we would recommend that the magnet is de-energized in a controlled manner to prevent a quench. Please contact us ASAP in this case. We would need to advise on the minimum helium level to do this safely, which depends on the magnet type.
For any questions or concerns, we can be reached by calling our office on +44 (0)1707 377117, or by email at NMRsupport@jeoluk.com
JEOL Ltd. (headquartered in Akishima, Tokyo; JEOL hereafter) acquired all shares of INTEGRATED DYNAMIC ELECTRON SOLUTIONS, INC. (headquartered in California, USA; IDES hereafter), an entrepreneurial venture specialized in technologies related to transmission electron microscopy (TEM hereafter), and made IDES its wholly-owned subsidiary.
Read the full press release here
Today was the unveiling of the new JEOL 600 MHz NMR facility at DMU.
There was an excellent line up of keynote speakers, presentations, and posters for the inauguration symposium.
Thank you to all of the staff at DMU for a great day.
JEOL (UK) Ltd respects your privacy and is committed to protecting your personal data. This privacy notice will inform you as to how we look after your personal data when you visit our website (regardless of where you visit it from) and tell you about your privacy rights and how the law protects you.
Read the full policy here
Seminar on the 17th May to highlight current and emerging opportunities provided by electron microscopy in the life sciences and to celebrate the renovation and reequip of CUI at King’s College London.
Click here to view the full invitation and programme.
Last week the annual ‘JEOL Postdoc Poster Competition’ took place at The University of York - Department of Chemistry
The standard of the entries was again very high, making the judge's job very difficult.
The winners are…
- Aggie Lawer - "Selective fluorination: a tool to control peptides' conformation and biological activity"
- Peter Rayner - "Tunable Catalysts for Hyperpolarisation"
And the runners-up…
Fergal Byrne - "2,2,5,5-Tetramethyloxolane (TMO): An Unusual Ether Which Can Replace Hazardous Hydrocarbon Solvents"
Sandra Greive - "Probing the function of a thermostable viral portal protein using single-molecule electrical sensing"
- Petr Slavík - "DBS-CONHNH2 Hydrogels with Embedded Catalytically-Active Metal Nanoparticles"
- Carmen Piras - "Spatial control of multicomponent self-assembled gels
Thank you to everyone who entered and congratulations to the winners!
We are very honoured to be at the launch of the Rosalind Franklin Institute today.
Following the announcement in February 2018 of an initial £1.55m investment to fund the development of a unique time-resolved high-resolution transmission electron microscope, the purchase of the JEOL FIB with assistance from the MRC, Diamond Light Source and the RCaH, is the first stage in what will be a long term project.
The newly developed JIB-4700F utilises a Focussed Ion Beam column with a high-current density Ga ion source providing up to 90nA of probe-current. The high current provides for the fast ion milling and processing of specimens. The SEM optics feature an "in-lens Schottky-emission electron gun" that produces an electron beam with a maximum probe-current of 300nA, which allows for simultaneous high-resolution observations and fast analyses. This field emission SEM additionally features a hybrid conical objective lens, GENTLEBEAM™ (GB) mode and an in-lens detector system to deliver a guaranteed resolution of 1.6nm at a low accelerating voltage of 1 kV.
In parallel with high-speed cross-section processing by FIB, high-resolution SEM observations and fast analyses can be conducted utilizing energy dispersive X-ray spectroscopy (EDS) and electron backscatter diffraction (EBSD). Additionally, a three-dimensional analysis function that automatically captures SEM images at regular intervals during cross-section processing is provided as one of the JIB-4700F's standard features.
JEOL UK is proud to announce that the Scottish Cryo-EM consortium has chosen the JEOL JEM-Z300FSC CRYO ARM™ 300 as their preferred automated Cryo Transmission Electron Microscope (Cryo-TEM) for the Scottish Centre for Macromolecular Imaging (SCMI).
The SCMI consortium led by the MRC Centre for Virus Research (CVR) at The University of Glasgow, selected JEOL after a thorough evaluation of the competing technologies for cryo-TEM. The JEOL CRYO ARM™ 300 will be supported by a second TEM, the JEOL 200kV JEM-F200 “F2” Cryo-TEM.
Project lead and programme leader in the CVR, Dr David Bhella said:
“The mission of the CVR is to carry out fundamental research on viruses and viral diseases, translating the knowledge gained for the improvement of health and benefit of society.
Cryogenic transmission electron microscopy is revolutionising the field of structural biology. The SCMI represents a tremendous opportunity not only for the CVR, but also for Life Scientists throughout Scotland. The new facility will place Glasgow at the centre of vital structural biology research by offering world-class capability. The new technology will help us investigate key processes in cancer biology and infection”.
Cryo-EM has gained enormous momentum in recent years resulting in the award for the Nobel Prize in Chemistry.
Ultra-high resolution structural analysis of viruses and proteins derived from cryo-EM techniques such as Single Particle Analysis (SPA) require high stability hardware and software.
The JEOL CRYO ARM™ 300 is the latest offering in cryo-TEM, able to achieve unprecedented resolution and stability by including Cold Field Emission Gun; in-column Omega energy filter; Hole-Free Phase Plate; side-entry liquid nitrogen cooling stage and an automated 12 specimen storage and exchange system.
The JEM-F200 "F2” is a high throughput TEM and the only 200kV system in its class to offer a Cold Field Emission Gun. The 'F2' employs the latest JEOL innovations in an easy-to-use, extremely stable, high resolution imaging 200kV TEM with STEM. This makes it the ideal partner for any high-level cryo-TEM.
JEOL look forward to helping and supporting Dr David Bhella and colleagues in the SCMI consortium in their research activities using the new instruments.
Pioneering centre for nanoscale materials research launched on Harwell Campus
Industry, press and leading scientists have gathered for the opening of a pioneering new centre for the study of nanoscale materials located at Diamond Light Source. The launch of this unique centre is set to boost the UK’s world-leading science and technology infrastructure.
Oxfordshire’s cutting-edge electron Physical Sciences Imaging Centre (ePSIC) is the result of the collaboration between a research facility, academia and industry. Diamond Light Source, the UK’s synchrotron, partnered with the University of Oxford and the global speciality chemicals company, Johnson Matthey to bring a unique set of tools to the centre. Funding for the construction of the new Diamond building housing ePSIC included contributions from the Wellcome Trust, the Biotechnology
Biological Sciences Research Council and a £2M contribution from the Science and Technology Facilities Council.
The internationally leading centre for UK science contains two state-of-the-art electron microscopes for the physical sciences, designed to provide scientists with atomic-level images in a range of technologically important materials.
Today Johnson Matthey, Oxford University and Diamond Light Source announce the creation of a state-of-the-art materials characterisation facility at the Harwell Science and Innovation Campus. This world-class site is close to both Oxford University and Johnson Matthey’s Sonning Common Research laboratories and is home to Diamond, the UK’s synchrotron science facility, where currently 24 experimental stations (beamlines) are operational with funding in place to increase this number to 33 by 2018.
Read the full press release here
The National Management Committee of the UK 850 MHz Solid-State NMR facility, based at the University of Warwick, today announced the award of the contract to supply a 1 mm CPMAS solid-state NMR probe for their 850 MHz widebore system to JEOL (UK) Limited. This will be the first 1 mm solid-state probe to be supplied in Europe.
The EPRSC, BBSRC & Birmingham Science City (AWM & ERDF) funded UK 850 MHz Solid-State NMR facility has been in operation since February 1st 2010 delivering advances in Materials Science, Chemistry, Biology, Earth Sciences and Physics, with time allocated to date to scientists from 16 UK universities.
Mr Peter Meadows, European Product Manager for NMR at JEOL said "The addition of the 1 mm CPMAS probe to the JEOL portfolio of products supports and strengthens our position in Solid-State NMR. JEOL’s 1 mm CPMAS probe is the first commercially available probe to deliver magic angle spinning (MAS) speeds from 1 kHz to 80 kHz stable to < 10 Hz; it features strong rf fields, and provides high sensitivity per unit volume."
For further information on the 1 mm CPMAS Solid-State NMR Probe or other JEOL products, please contact email@example.com or your local JEOL office.
JEOL is a leading supplier of nuclear magnetic resonance (NMR) spectrometers, mass spectrometers, scanning electron microscopes (SEMs), transmission electron microscopes (TEMs), scanning probe microscopes (SPMs), and semiconductor tools for scientific and industrial purposes. Providing application-specific solutions that advance our customers' diverse objectives — from routine analysis of organic and inorganic specimens to breakthroughs in nanotechnological development.
For further information, please visit www.jeol.com
JEOL has brought the relatively recent multi-touch interactive computing technology to a research-grade scientific instrument. The InTouchScope software interface has the familiar look and feel of today's personal electronic media. This is an SEM with an easy-to-learn, intuitive software interface with all the capabilities of a full-grade, variable pressure SEM.
The InTouchScope will be demonstrated at EMAG 2011 on 6-9 September at the University of Birmingham.
To book a demonstration please contact our Sales Department on 01707 377117 or email us at firstname.lastname@example.org
SF6 (sulphur hexafluoride) is used extensively in TEMs as a high voltage insulator because of its high resistance to electrical breakdown. Unfortunately, it is both a potent greenhouse gas and highly inert, remaining in the atmosphere for many years.
EU legislation in July, 2006 imposed strict control on the handling of SF6, making it illegal to release SF6 into the atmosphere. As part of JEOL’s ISO 14001:2004 Environmental Accreditation, JEOL’s manufacturing facilities invested in the necessary equipment well before the regulations came into effect.
JEOL has now invested within the UK in the necessary equipment and Service Engineer training to enable JEOL to undertake SF6 recovery and recycling in-house, further extending JEOL’s commitment to customer support. We believe this investment makes JEOL the only electron microscope supplier in the UK with this in-house capability.
As well as handling SF6 for our own instruments, JEOL is offering SF6 recovery as a service to universities, laboratories and other instrument suppliers. Contact Customer Support UK.SVC@jeoluk.com for further information.
